Ameise® PTM 2.0 Scale pallet truck with precision scale, load capacity 2,000 kg
slide 1 of 3
Free shipping from £50 (plus VAT)
Secure data protection
Personal purchasing advice
Technical details
Ameise® PTM 2.0 Scale pallet truck with precision scale, load capacity 2,000 kg
Article number: 199564 | EAN/GTIN: 4055091198866
| Automatic shut-off without insert | 30 min |
| Battery capacity | 1,2 Ah/per unit |
| Battery voltage | 12 V/per unit |
| Battery weight | 1.51 kg |
| Brand | Ameise® |
| Capacity | 2000 kg |
| Charger | including |
| Chassis RAL colour | RAL 5018 turquoise blue |
| Chassis surface | powder-coated |
| Control panel | right-handed |
| Design | Without option |
| Digit unit | Up to 200 kg in 200 g increments; up to 500 kg in 500 g increments; up to 2000 kg in 1000 g increments |
| Drive | manual |
| Face of forks length | 410 mm |
| Fork length | 1150 mm |
| Fork roller diameter | 74 mm |
| Fork roller equipment | Single |
| Fork roller material | Polyurethane (PU) |
| Fork roller width | 93 mm |
| Fork width | 180 mm |
| Ground clearance | 22 mm |
| Handle fittings | Rubber sheath |
| Hydraulic oil quantity | 0.3 l |
| Hydraulic oil type | Mineral oil |
| Hydraulic oil viscosity acc. to ISO-VG | 32 |
| IP protection type display | IP 65 |
| IP protection type measuring cells | IP 67 |
| Lift | 110 mm |
| Lift height per pump stroke | 18 mm |
| Lift range | 90 - 200 mm |
| Load centre | 600 mm |
| Measuring tolerance | 0.1 % |
| Model | Ameise® PRO |
| Net weight | 109 kg |
| Net weight incl. battery | 109 kg |
| No. of batteries | 1 |
| Noise damping | Yes |
| Operator type | Manual |
| Overall length | 1560 mm |
| Overall width | 555 mm |
| Pallet truck material | Steel |
| Power supply scale | Battery |
| Pump strokes to lift pallet | 2 |
| Pump strokes to max. lift height | 6 |
| Rapid lift | Yes |
| Route | Short distance |
| Scale type | digital |
| Section | Performance |
| Steering radius | 110 ° |
| Steering wheel diameter | 180 mm |
| Steering wheel material | Solid rubber |
| Steering wheel width | 50 mm |
| Temperature range | -10 - 40 °C |
| Tiller RAL colour | RAL 9005 deep black |
| Tiller height | 1210 mm |
| Tiller surface | powder-coated |
| Turning radius | 1350 mm |
| Weighing range | 200 / 500 / 2.000 kg |
| Zero adjustment via keyboard | Yes |
| Automatic shut-off without insert | 30 min |
| Battery capacity | 1,2 Ah/per unit |
| Battery voltage | 12 V/per unit |
| Battery weight | 1.51 kg |
| Brand | Ameise® |
| Capacity | 2000 kg |
| Load centre | 600 mm |
| Measuring tolerance | 0.1 % |
| Model | Ameise® PRO |
| Net weight | 109 kg |
| Net weight incl. battery | 109 kg |
| No. of batteries | 1 |
Item description
Ameise® PTM 2.0 Scale pallet truck with precision scale, load capacity 2,000 kg
Article number: 199564 | EAN/GTIN: 4055091198866
The weighing scale pallet truck for industrial use
The Ameise® PRO weighing scale pallet truck is a mobile weighing station for industrial applications. The precision scale features a multi-range display, which measures and displays the weight in increments of 0.2 kg up to 200 kg, 0.5 kg from 200 to 500 kg and 1 kg from 500 to 2000 kg. In all cases, the maximum deviation amounts to 0.1% of the measured weight. The scale features automatic and manual zero correction, gross/net weight display, automatic tare and tare preset as well as a totals memory with sequential numbering.
Power is supplied by a rechargeable lead-gel battery pack, which lasts for up to 35 hours. An external battery charger is also supplied as standard. The display will inform you in good time when the battery needs to be recharged. You also have the option of purchasing additional battery packs. The plug-in battery packs are replaced in a flash so that your weighing scale pallet truck is immediately ready for use. To minimise energy consumption, the scale switches off automatically when not used for approx. 30 minutes. The display terminal is further protected by a metal housing.
The robust pallet truck offers tried and tested Ameise® quality. The durable high-performance hydraulic pump is made from high-quality steel with hard chrome-plated pressure pistons to cope with the rigours of continuous daily use. The quick lift function up to 120 kg saves you time and energy during everyday pallet handling. The steering castors with solid rubber tyres combined with the polyurethane fork rollers ensure comfortable, low-noise travel with perfect grip. Depending on the ground conditions, you can choose between single or tandem rollers.
You also have the option of equipping the Ameise® PRO weighing scale pallet truck with other useful functions and accessories. In addition to the replacement battery pack mentioned above, a thermal printer and foot brake are also available for the pallet truck. We also offer an adjustment certificate, a finer multi-range display and a calibrated version of the weighing scale pallet truck. Order the Ameise® PRO weighing scale pallet truck from our shop in your chosen configuration.
The Ameise® PRO weighing scale pallet truck is a mobile weighing station for industrial applications. The precision scale features a multi-range display, which measures and displays the weight in increments of 0.2 kg up to 200 kg, 0.5 kg from 200 to 500 kg and 1 kg from 500 to 2000 kg. In all cases, the maximum deviation amounts to 0.1% of the measured weight. The scale features automatic and manual zero correction, gross/net weight display, automatic tare and tare preset as well as a totals memory with sequential numbering.
Power is supplied by a rechargeable lead-gel battery pack, which lasts for up to 35 hours. An external battery charger is also supplied as standard. The display will inform you in good time when the battery needs to be recharged. You also have the option of purchasing additional battery packs. The plug-in battery packs are replaced in a flash so that your weighing scale pallet truck is immediately ready for use. To minimise energy consumption, the scale switches off automatically when not used for approx. 30 minutes. The display terminal is further protected by a metal housing.
The robust pallet truck offers tried and tested Ameise® quality. The durable high-performance hydraulic pump is made from high-quality steel with hard chrome-plated pressure pistons to cope with the rigours of continuous daily use. The quick lift function up to 120 kg saves you time and energy during everyday pallet handling. The steering castors with solid rubber tyres combined with the polyurethane fork rollers ensure comfortable, low-noise travel with perfect grip. Depending on the ground conditions, you can choose between single or tandem rollers.
You also have the option of equipping the Ameise® PRO weighing scale pallet truck with other useful functions and accessories. In addition to the replacement battery pack mentioned above, a thermal printer and foot brake are also available for the pallet truck. We also offer an adjustment certificate, a finer multi-range display and a calibrated version of the weighing scale pallet truck. Order the Ameise® PRO weighing scale pallet truck from our shop in your chosen configuration.
