Item number:
197981
Drum lifter with foot pedal, corner pick-up, lift height 500 mm, capacity 450 kg, RAL 3020 traffic red
For 200 litre steel drums
Technical details
Drum lifter with foot pedal, corner pick-up, lift height 500 mm, capacity 450 kg, RAL 3020 traffic red
-
Capacity450 kg
-
Castor locking functionmanual
-
Chassisspread
-
Deliveryfully assembled
-
Depth900 mm
-
Fixed castor diameter125 mm
-
Height1260 mm
-
Hydraulic oil quantity0.75 l
-
Hydraulic oil viscosity acc. to ISO-VG46
-
Jack functionsclamp, grip, lift, lower
-
Lift height maximum500 mm
-
Lift typemanual
-
MaterialIron
-
Net weight107 kg
-
No. of fixed castors2 Stk.
-
No. of swivel castors2 Stk.
-
RAL colourRAL 3020 traffic red
-
SectionStarter
-
Swivel castor diameter125 mm
-
Width1120 mm
Item description
Drum lifter with foot pedal, corner pick-up, lift height 500 mm, capacity 450 kg, RAL 3020 traffic red
These drum lifters enable ergonomic and time-saving handling of 200 litre steel drums. Our range includes special versions for picking up pallets from the front or from the corner.
- Drum lifter with pedal for effortless lifting
- Gentle automatic latching mechanism for drum pick-up
- Drums positioned centrally on pallets can be lifted with ease
For efficient drum transport on your premises
These drum lifters with foot pedal operation and handles enable quick pick-up and effortless lifting of 200 litre steel drums, which then can be transported with utmost ease and deposited with maximum precision.
The drum lifter easily reaches drums positioned in the middle of pallets. The rollers are equipped with wheel stops for security and stability. Our range includes a version with wide arms for picking up pallets from the front as well as a second model with a splayed front end for approaching pallets from the corner.
Order the drum lifter with foot pedal operation from our shop in your required version.
These drum lifters with foot pedal operation and handles enable quick pick-up and effortless lifting of 200 litre steel drums, which then can be transported with utmost ease and deposited with maximum precision.
The drum lifter easily reaches drums positioned in the middle of pallets. The rollers are equipped with wheel stops for security and stability. Our range includes a version with wide arms for picking up pallets from the front as well as a second model with a splayed front end for approaching pallets from the corner.
Order the drum lifter with foot pedal operation from our shop in your required version.
