Item number:
194258
Jungheinrich AM I20 stainless steel pallet truck, 1,220 mm fork length, nylon
All-round protection for reliable use in humid and harsh environments
Free shipping from £50 (plus VAT)
Secure data protection
Personal purchasing advice
Technical details
Jungheinrich AM I20 stainless steel pallet truck, 1,220 mm fork length, nylon
Article number: 194258 | EAN/GTIN: 4055091186375
| Aisle width | 1810 mm |
| Brand | Jungheinrich |
| Capacity | 2000 kg |
| Chassis surface | electropolished |
| Control panel | two-handed |
| Drive | manual |
| Face of forks length | 335 mm |
| Fork height | 51 mm |
| Fork length | 1220 mm |
| Fork roller diameter | 80 mm |
| Fork roller equipment | Single |
| Fork roller material | Nylon |
| Fork roller width | 90 mm |
| Fork support width | 520 mm |
| Fork width | 160 mm |
| Grease nipple | Yes |
| Ground clearance | 38 mm |
| Handle fittings | Plastic |
| Lift | 120 mm |
| Lift height per pump stroke | 12 mm |
| Lift range | 85 - 205 mm |
| Load centre | 610 mm |
| Lowering speed with/without load | 0,1 / 0,05 m/s |
| Model | Jungheinrich AM I20 |
| Net weight | 72 kg |
| Operator type | Manual |
| Overall length | 1555 mm |
| Overall width | 520 mm |
| Pallet truck material | Stainless steel |
| Pump strokes to lift pallet | 2 |
| Pump strokes to max. lift height | 10 |
| Rapid lift | Yes |
| Route | Short distance |
| Section | Professional |
| Steering radius | 220 ° |
| Steering wheel diameter | 200 mm |
| Steering wheel material | Nylon |
| Steering wheel width | 50 mm |
| Temperature range | -40 - 50 °C |
| Tiller height | 1220 mm |
| Tiller surface | electropolished |
| Turning radius | 1410 mm |
Product Notes
Our offer is aimed exclusively at commercial customers (entrepreneurs). In particular, the product is not intended for use by consumers.
Warning and safety information
Data sheets & instructions
Item description
Jungheinrich AM I20 stainless steel pallet truck, 1,220 mm fork length, nylon
Article number: 194258 | EAN/GTIN: 4055091186375
The Jungheinrich AM I20 hand pallet truck with long forks is ideal for use in the food industry or in areas prone to high levels of corrosion, such as those encountered in the chemical and pharmaceutical industries. The AM I20 stainless steel pallet truck is particularly beneficial in areas with high hygiene requirements.
- Corrosion and acid-resistant chassis
- Closed fork tips to protect against dirt splashes
- Easy to clean
- Sliding brackets for easier pallet lifting
- Food-grade lubricants (class H1/H2)
Jungheinrich AM I20 hand pallet truck made from stainless steel – for harsh environments and high hygiene requirements
Our Jungheinrich AM I20 stainless steel pallet truck with long forks is ideal for transporting overlong load carriers.
The long fork pallet truck offers a capacity of 2,000 kg. The capacity remains the same across the entire fork length, provided that the load is evenly distributed around load centre. Despite the long forks, the stainless steel pallet truck is extremely agile and easy to manoeuvre thanks to the 220° steering radius.
The stainless steel chassis of the AM I20 pallet truck is acid-resistant and offers long-term corrosion protection even in the most humid environments. This makes the pallet truck ideal for use in the chemical and pharmaceutical industry. The stainless steel pallet truck also satisfies the stringent hygiene requirements of the food sector. All parts that come into direct contact with food products are made from acid-resistant stainless steel. Closed fork tips ensure that the fork rollers do not spray any water or dirt onto the transported load. Cavities are either freely accessible or fully sealed to enable effective cleaning. Only food-grade lubricants of class H1/H2 are used.
You operate the robust and reliable hand pallet truck via a functional control element that is equally well suited to both left and right-handed users. The very short headlength enables safe, effortless use in even the tightest of spaces. Pallets are picked up with ease thanks to the entry rollers and sliding brackets on the fork tips. In our shop, the Jungheinrich AM I20 stainless steel pallet truck with long forks is available with a range of different steering castors and fork rollers made from either nylon or polyurethane. Polyurethane tyres ensure maximum comfort and quiet operation, while nylon tyres are characterised by their robustness and high chemical resistance. You also have a choice between single or tandem fork rollers.
The Jungheinrich AM I20 stainless steel pallet truck with long forks and 2,000 kg capacity is the perfect choice for humid and harsh environments. Order the pallet truck for exacting requirements from our shop in your chosen configuration.
Our Jungheinrich AM I20 stainless steel pallet truck with long forks is ideal for transporting overlong load carriers.
The long fork pallet truck offers a capacity of 2,000 kg. The capacity remains the same across the entire fork length, provided that the load is evenly distributed around load centre. Despite the long forks, the stainless steel pallet truck is extremely agile and easy to manoeuvre thanks to the 220° steering radius.
The stainless steel chassis of the AM I20 pallet truck is acid-resistant and offers long-term corrosion protection even in the most humid environments. This makes the pallet truck ideal for use in the chemical and pharmaceutical industry. The stainless steel pallet truck also satisfies the stringent hygiene requirements of the food sector. All parts that come into direct contact with food products are made from acid-resistant stainless steel. Closed fork tips ensure that the fork rollers do not spray any water or dirt onto the transported load. Cavities are either freely accessible or fully sealed to enable effective cleaning. Only food-grade lubricants of class H1/H2 are used.
You operate the robust and reliable hand pallet truck via a functional control element that is equally well suited to both left and right-handed users. The very short headlength enables safe, effortless use in even the tightest of spaces. Pallets are picked up with ease thanks to the entry rollers and sliding brackets on the fork tips. In our shop, the Jungheinrich AM I20 stainless steel pallet truck with long forks is available with a range of different steering castors and fork rollers made from either nylon or polyurethane. Polyurethane tyres ensure maximum comfort and quiet operation, while nylon tyres are characterised by their robustness and high chemical resistance. You also have a choice between single or tandem fork rollers.
The Jungheinrich AM I20 stainless steel pallet truck with long forks and 2,000 kg capacity is the perfect choice for humid and harsh environments. Order the pallet truck for exacting requirements from our shop in your chosen configuration.
