Item number: 164704

Jungheinrich AMX I15ep stainless steel scissor lift pallet truck - professional version, capacity 1,500 kg, nylon

Name: Jungheinrich AMX I15ep stainless steel scissor lift pallet truck - professional version, capacity 1,500 kg, nylon
Brand: Jungheinrich
SKU: 164704
Price: 10300.0 GBP
Availability: InStock

With electric lift – for harsh environments and exacting hygiene standards

Go to product description

Jungheinrich AMX I15e stainless steel scissor lift pallet truck

Select variant:

Fork length:

Fork roller equipment:

Fork roller material:

Nylon

Polyurethane (PU)

Steering wheel material:

Nylon

Polyurethane (PU)

54 Working days

£10,300.00

per Stk excl. VAT plus shipping

Technical details

Jungheinrich AMX I15ep stainless steel scissor lift pallet truck - professional version, capacity 1,500 kg, nylon

Aisle width

1890 mm
Battery capacity

70 Ah/per unit
Battery type

Lead-gel battery
Battery voltage

12 V/per unit
Battery weight

21 kg
Brand

Jungheinrich
Capacity

1500 kg
Charger

integrated
Chassis surface

glass-bead blasted
Control panel

two-handed
Drive

manual
Face of forks length

445 mm
Fork height

50 mm
Fork length

1.200 mm
Fork roller diameter

80 mm
Fork roller equipment

Tandem
Fork roller material

Nylon
Fork roller width

60 mm
Fork support width

540 mm
Fork width

163 mm
Grease nipple

Yes
Ground clearance

19 mm
Handle fittings

Stainless steel
Lift

710 mm
Lift motor output

1.2 kW
Lift range

85 - 795 mm
Lift speed with/without load

0.05 / 0.08 m/s
Lift type

electric
Load centre

600 mm
Lowering speed with/without load

0,07 / 0,05 m/s
Model

Jungheinrich AMX I15ep
Net weight

140 kg
Operator type

Manual
Overall length

1645 mm
Overall width

540 mm
Pallet truck material

Stainless steel
Route

Short distance
Section

Professional
Steering radius

180 °
Steering wheel diameter

150 mm
Steering wheel material

Nylon
Steering wheel width

45 mm
Temperature range

5 - 40 °C
Tiller height

1270 mm
Tiller surface

glass-bead blasted
Turning radius

1540 mm

Item description

Jungheinrich AMX I15ep stainless steel scissor lift pallet truck - professional version, capacity 1,500 kg, nylon

The Inox professional version of the electro-hydraulic Jungheinrich AMX I15ep scissor lift pallet truck is a premium stainless steel pallet truck. It is fully corrosion and acid-resistant and meets the most stringent hygiene requirements. This makes the electric scissor lift pallet truck ideal for humid and harsh environments or applications with stringent hygiene requirements. It is particularly well suited to the chemical, pharmaceutical and food industries.

Fully corrosion, salt and acid-resistant
Sealed hydraulics prevent ingress of water
Easy to clean
Food-grade lubricants (class H1/H2)
1.2 kW lift motor for easy load handling
1,500 kg capacity

The AMX I15ep - the Jungheinrich premium model for exacting demands

The Inox professional version of the stainless steel scissor lift pallet truck is fully corrosion and acid-resistant and was designed specifically for harsh working environments. In addition, the scissor lift pallet truck with electric lift meets the most stringent hygiene requirements. This makes the AMX I15ep ideal for use in the chemical, pharmaceutical and food industries.

The pallet truck hydraulics are specially protected to prevent ingress of foreign bodies and water. Closed fork tips ensure that the fork rollers do not spray any water or dirt onto the transported load. Cavities are either freely accessible or fully sealed to enable effective cleaning – bacteria has no place to hide! This is further facilitated by the electrically polished surfaces. Only food-grade lubricants of class H1/H2 are used.

The robust and reliable scissor lift pallet truck is operated via a functional control element. With the electrohydraulics, you can easily raise and lower the loads at the touch of a button. The scissor lift pallet truck can transport loads weighing up to 1,500 kg or raise them to an ergonomic working height. As of a lift height of 470 mm, the capacity is reduced to 1000 kg. You can adjust your individual working height up to a maximum of 795 mm. As of a lift height of approx. 400 mm, side-mounted support feet secure the scissor lift pallet truck for additional safety and stability.

A pressure relief valve protects the hydraulic system against overload. The robust, torsion-free construction of the fork arms retains its shape even when subjected to maximum loads.

Depending on your specific application, you can opt for steering castors and fork rollers in either nylon or polyurethane. Polyurethane tyres ensure maximum comfort and quiet operation, while nylon tyres are characterised by their robustness and high chemical resistance. The tandem fork rollers ensure smooth running over uneven floors.

The Jungheinrich AMX I15ep stainless steel scissor pallet truck with electric lift is an ideal choice for harsh chemical environments or areas with stringent hygiene standards. Order the premium model for the most exacting demands from our shop in your chosen configuration.
