Name: Jungheinrich EJC 112zi ZZ electric high-lift stacker truck, lift 2,300 mm, on-board charger, proportional hydraulics
Brand: Jungheinrich
SKU: 484901
Price: 10400.0 GBP
Availability: InStock

Technical details

Jungheinrich EJC 112zi ZZ electric high-lift stacker truck, lift 2,300 mm, on-board charger, proportional hydraulics

Access system

PIN-Code
Additional wheel width

54 mm
Aisle width

2186 mm
Automatic shut-off without insert

5 min
Battery capacity

150 Ah/per unit
Battery charging time

3 h
Battery type

Lithium-ion
Battery voltage

24 V/per unit
Battery weight

47 kg
Brake

generator
Brand

Jungheinrich
Capacity

1200 kg
Charger

integrated
Chassis surface

powder-coated
Colour chassis

Jungheinrich yellow
Control panel

two-handed
Creep speed button

Yes
Display

2" Display
Drive

electric
Drive control type

AC speed control
Drive motor power

0.9 kW
Drive wheel diameter front

230
Drive wheel material

Polyurethane (PU)
Drive wheel width front

70
Face of forks length

749 mm
Fork height

56 mm
Fork length

1150 mm
Fork roller diameter

85 mm
Fork roller equipment

Single
Fork roller material

Polyurethane (PU)
Fork roller width

95 mm
Fork support width

570 mm
Fork width

185 mm
Free lift

1125 mm
Ground clearance

18 mm
Herstellungsort

Made in Germany
Hour meter

Yes
Initial lift

122 mm
Lift

2300 mm
Lift motor output

2.2 kW
Lift range

90 - 2300 mm
Lift speed with/without load

0,16 / 0,29
Load centre

600 mm
Lowering speed with/without load

0,41 / 0,37
Mast

Two-stage telescopic mast (ZT)
Mast height

1600 - 2775 mm
Model

Jungheinrich EJC 112zi
Net weight incl. battery

872 kg
No. of batteries

1
Noise level as per EN 12053 (operator's ear)

65 dB(A)
Operator type

Pedestrian
Overall length

1899
Overall width

800 mm
Route

Short distance
Scope

Indoor, Outdoor (roofed)
Section

Professional
Spare wheel diameter

140 mm
Steigfähigkeit mit/ohne Last

5 / 14
Telematics box

Yes
Temperature range

-10 - 40 °C
Tiller RAL colour

RAL 7016 anthracite grey
Tiller height

750 - 1260 mm
Tiller surface

powder-coated
Travel speed, laden/unladen

6 / 6
Turning radius

1700 mm
quality seal

LI-ION technology

Item description

Jungheinrich EJC 112zi ZZ electric high-lift stacker truck, lift 2,300 mm, on-board charger, proportional hydraulics

The Jungheinrich EJC 112zi ZZ with lithium-ion battery is a premium product "Made in Germany". The electric high-lift stacker truck with two-stage telescopic mast and free lift impresses with its high performance, innovative technology, ergonomics and high safety standards. This makes it the ideal tool for efficient pallet handling and high productivity, be it for internal goods transport over short distances with loads weighing up to 1,200 kg or for storing and retrieving goods at heights of up to 3,900 mm. Thanks to the additional support arm lift, the EJC 112zi easily negotiates thresholds and ramps, thereby ensuring maximum flexibility. The maintenance-free lithium-ion battery with integrated charger impresses with its constant performance levels, short charging times and long service life.

Premium quality "Made in Germany"
Support arm lift for flexible use on ramps and thresholds
1,200 kg load capacity
6 different lift heights available (2,300, 2,500, 2,900, 3,200, 3,600 and 3,900 mm)
Maintenance-free 150 Ah lithium-ion battery
Lithium iron phosphate cell technology (LiFePO)
Jungheinrich Li-ion Guarantee Plus for up to 8 years warranty
Powerful on-board charger for easy rapid and intermediate charging
Proportional hydraulics for precision lifting and lowering
3 selectable travel speeds up to 6 km/h
Low overall height, small turning circle, compact dimensions
For confined spaces and narrow aisles
Slow travel button for safe operation in tight spaces
PIN code access protects against unauthorised use
2" display provides information on truck and battery status

Performance class with additional support arm lift for greater ground clearance and increased flexibility in use

The EJC 112zi ZZ represents Jungheinrich's performance class and impresses with its high performance, innovative technology and premium quality "Made in Germany". The electric high-lift stacker truck with lithium-ion battery, two-stage telescopic mast and free lift is a versatile all-rounder for demanding applications. It makes light work of transporting loads weighing up to 1,200 kg across short distances and stacking or retrieving pallets at heights of up to 3,900 mm. The additional support arm lift ensures even greater flexibility in use. The additional lift serves as a second lift mechanism, allowing the support arms to be raised independently of the fork arms. As a result, the EJC 112zi easily negotiates uneven floors, ramps, thresholds or loading bridges. The initial lift also enables transverse pick-up of Euro pallets, the correct position of which can be checked via the convenient fork marking.

Whether in a warehouse, salesroom, production facility or workshop – the low overall height, small turning circle and narrow aisle width make the space-saving electric pedestrian stacker highly manoeuvrable and thus particularly suitable for use in tight spaces. You can even work effortlessly and efficiently in confined storage areas, as the small turning radius reduces the risk of damage to your goods. And when things get really tight, you can activate slow travel mode to manoeuvre the high-lift stacker safely and comfortably at reduced speed with the tiller raised.

The electric stacker truck impresses with its ease of use thanks to a simple and intuitive operating concept. You activate the high-lift stacker truck using a PIN code and control all travel, lifting and lowering functions via the ergonomic multifunction tiller head, which can be operated with either hand. Important control instruments such as the battery charge level, operating hour counter, travel speed and status messages are always in your field of vision on the 2" display. The proportional hydraulics allow you to deposit sensitive loads on the rack or ground with maximum care.

The EJC 112zi provides you with everything you need to ensure rapid, energy-efficient and cost-effective goods turnover. 3 travel programmes allow you to set an individual travel speed up to 6 km/h. When activated, the truck always starts with the last travel programme to be used. The necessary energy is provided by the powerful 150 Ah lithium-ion battery, which impresses with its consistently high performance. It is characterised by low energy consumption and, in comparison to lead-acid batteries, is maintenance-free and offers a three times longer service life. Another plus point: With the Jungheinrich Li-ion Guarantee Plus, Jungheinrich offers a long-term performance promise of up to 8 years on its high-quality lithium-ion batteries.

Simple rapid and intermediate charging of the battery is possible without memory effect, thereby ensuring maximum availability and flexibility of your lithium-ion truck at all times. Thanks to the powerful on-board charger, the battery can be easily recharged via any 230-V socket. With a battery heater installed as standard, the operating temperature of the high-lift truck is between -10°C and +40°C. A specially developed battery management system ensures safe operation and switches the truck off automatically when not in use. The clever energy recovery during braking saves energy and thus contributes to high energy efficiency.

The low overall height and excellent visibility through the mast ensure safe working, as the forks, load and surrounding areas are always in view. This speeds up the storage and retrieval process. The four-wheel chassis ensures that the truck is always secure and stable. The Plexiglas panel in front of the mast prevents accidental reaching through. The minimal ground clearance of just 18 mm and the fully encased housing provide effective protection against foot injuries. An easily accessible emergency disconnect switch and the collision safety switch integrated in the tiller head ensure optimum protection in dangerous situations.

All Jungheinrich electric stacker trucks are attended to by our outstanding Jungheinrich service. With more than 3000 service engineers worldwide, we guarantee a partner in your vicinity at all times along with an optimum spare parts supply.

The Jungheinrich EJC 112zi ZZ electric high-lift stacker truck with two-stage telescopic mast, free lift and lithium-ion battery also features an additional initial lift for flexible operation on thresholds and ramps. Order the premium truck for demanding applications from our shop in your required lift height.
