Item number:
458340
Jungheinrich EKM 202 small parts order picker
The convenient solution for rapid and safe working at height
Free shipping from £50 (plus VAT)
Secure data protection
Personal purchasing advice
Technical details
Jungheinrich EKM 202 small parts order picker
Article number: 458340 | EAN/GTIN: 4055091288895
| Battery capacity | 192 Ah/per unit |
| Battery type | Lead-gel battery |
| Battery voltage | 24 V/per unit |
| Battery weight | 120 kg |
| Brand | Jungheinrich |
| Capacity | 215 kg |
| Depth | 1520 mm |
| Design | - |
| Drive | electric |
| Drive motor power | 1.0 kW |
| Fixed castor diameter | 300 mm |
| Fixed castor width | 65 mm |
| Height when retracted | 1452 m |
| Lift | 3000 mm |
| Lift motor output | 2.2 kW |
| Lift speed with/without load | 0,14 / 0,19 m/s |
| Loading area type | Ladeplattform manuell höhenverstellbar |
| Lowering speed with/without load | 0,27 / 0,20 m/s |
| Mast height | 1410 - 4426 mm |
| Net weight | 615 kg |
| No. of batteries | 4 |
| No. of fixed castors | 2 Stk. |
| No. of swivel castors | 2 Stk. |
| Operator type | Order picker |
| Place of manufacture | Made in Germany |
| Platform depth | 595 mm |
| Platform width | 681 mm |
| Section | Professional |
| Standing height | 0,31 - 3,31 m |
| Swivel castor diameter | 250 mm |
| Swivel castor width | 50 mm |
| Travel speed, laden/unladen | 8 / 8 km/h |
| Turning radius | 1250 mm |
| Türverriegelung | Türen federbelastet |
| Warntöne | No |
| Width | 750 mm |
| Working height | 5,31 m |
Item description
Jungheinrich EKM 202 small parts order picker
Article number: 458340 | EAN/GTIN: 4055091288895
The EKM 202 small parts order picker makes ladders a thing of the past. It safely and reliably transports you to the required location, where it can be extended to an order picking height of 5.3 m and loaded with goods weighing up to 100 kg. The EKM 202 features a total capacity of 215 kg.
- 2.2 kW lift motor
- 192 Ah battery, maintenance-free
- On-board charger with spiral cable for any 230 V socket
- Automatically closing doors
- Lower shelf with 115 kg load capacity for additional storage space
- Robust steel frame and stable mast
Passenger lift, ladder and transport facility all in one
Enclosed in a robust steel frame, the EKM 202 small parts order picker from Jungheinrich not only impresses with its superior quality, but also with its superb flexibility. The EKM 202 is ideal for performing classic order picking duties in warehouses. However, due to its compact size with a width of just 760 mm, it is also suitable for smaller spaces such as stores. Thanks to the robust mast with an order picking height of 5.3 m, maintenance work on ceilings is just as easily accomplished as order picking activities on the third rack level.
Capacitive sensors are fitted for mandatory two-hand operation. This control method is not only intuitive, but also safe since the operator cannot reach outside the truck. The Jungheinrich EKM 202 small parts order picker is easily controlled via the convenient, ergonomic steering knob as well as a travel switch with thumb operation. A defined zero position ensures safe and simple reversing and straight-ahead travel.
The 2.2 kW lift motor raises the order picker reliably to the correct height, even while in motion. This allows you to move directly towards the relevant products on the rack. The doors close automatically to ensure that the operator area is secure before lifting commences. For additional safety, you can opt for a model with automatic locking. In this case, the doors cannot be opened until the order picker is fully lowered.
The EKM 202 features a total capacity of 215 kg, distributed across the platform and storage tray. The storage tray can hold up to 100 kg and features slotted holes to provide a clear view. When supporting several or larger items, it can be adjusted in height so that the operator once again has an unobstructed view.
We offer the small parts order picker in different versions. In addition to the base model, we also offer the EKM 202 with an electrically adjustable platform, automatic door locking, flashing lights and warning sounds, or only with the adjustable platform and automatic door locking.
Purchase the Jungheinrich EKM 202 small parts order picker from our shop and benefit from enhanced safety and greater productivity while reducing the strain on your employees.
